Level Gauge > BL_Series

  • With Protection Support Pipe
  • Gauge Valves Sold Separately
  • Economical Type
  • Suitable Fluid:  Water, Oil, other chemical liquid
  • Gauge Valve Material:  SS304 or SS316 available
  • Gauge Tube Material:  DURAN®Glass
  • Seal Material:  Viton or EPDM available
  • Protection Support Pipe Material:  Acrylic
  • Gauge Valve Function:  With or Without ball check
  • Max. Working Temperature:  120°C
  • Max. Working Pressure:  5~8 kg/cm²
    (Please alos consider of the function of length and temperature.)
  • Process Connection:  ½”~¾” Male Thread; and ⅜”~1″ Flange type on request
  • Process Type:  Thread G, NPT, BSPT available
    Flange JIS, ANSI, DIN available
  • Drain Valve Connection:  ¼” and ⅜” Female Thread G, NPT, BSPT available
  • Center to Center Length:  Max. 1500mm
Add to Wishlist
SKU: 2001 Category:

Description

  • With Protection Support Pipe
  • Gauge Valves Sold Separately
  • Economical Type
  • Suitable Fluid:  Water, Oil, other chemical liquid
  • Gauge Valve Material:  SS304 or SS316 available
  • Gauge Tube Material:  DURAN®Glass
  • Seal Material:  Viton or EPDM available
  • Protection Support Pipe Material:  Acrylic
  • Gauge Valve Function:  With or Without ball check
  • Max. Working Temperature:  120°C
  • Max. Working Pressure:  5~8 kg/cm²
    (Please alos consider of the function of length and temperature.)
  • Process Connection:  ½”~¾” Male Thread; and ⅜”~1″ Flange type on request
  • Process Type:  Thread G, NPT, BSPT available
    Flange JIS, ANSI, DIN available
  • Drain Valve Connection:  ¼” and ⅜” Female Thread G, NPT, BSPT available
  • Center to Center Length:  Max. 1500mm
