Description
- Model:
NL_Series: with protection support Rod
SL_Series: with protection support Pipe
- Suitable Fluid: Water, Oil, other chemical liquid
- Gauge Valve Material: SS304, SS316, others available
- Gauge Tube Material: Glass, PVC
- Seal Material: Viton, Teflon available
- Gauge Valve Function: With or Without ball check
- Max. Working Temperature: 100°C
- Max. Working Pressure: 4~7 kg/cm²
- Process Connection: ½”~1½” Thread and Flange on request
- Flange Rating: JIS, ANSI, DIN available
- Drain Valve Connection: standard ½”NPT(F), option available
Specifications
DOWNLOAD SPECS NL SL Series
